Platform Trailer
Platform Trailer
Platform trailer is the preferred type of trailer for transporting excess loads over 100 tons. Platform trailers are especially preferred for transporting high and wide loads that cannot be covered.
Platform trailer models are designed by the Vertisa expert and professional team in line with your needs. You can contact our technical teams now to get more detailed information about our platform-type trailer products.
- Catalog not yet loaded
| Technical Specifications |
| • Front Straight Line: 9,000mm – 13,600mm • Internal Width: 2,550mm • Height: 2,440mm • Side & Body Panels: 4 or 5 side panels mounted • Panel Attachment: Panels are externally fixed, 800mm – 900mm • Flooring: Composed of one metal sheet layer and one wooden layer • Reinforcements: Pressed “Z” cross members placed at intervals |
| Chassis |
| • Main Frame: Reinforced “I” section, 120/12.5 mm steel plate • Welding: Welded using an automatic submerged arc welding machine • Structure: Chassis interconnected for resistance to bending |
| Trailer Dimensions |
| • Standard Length: 13,600mm • Extendable Pilot Trailer Model: 13,600mm + 8,000mm (max) = 21,600mm • Width: 2,550mm |
| Capacity |
| • Maximum Gross Weight (2 Axles): 27,500 Kg • Maximum Gross Weight (3 Axles): 35,500 Kg • Maximum Gross Weight (4 Axles): 43,500 Kg |
| Axles and Suspension |
| • Axles: 2 or 3 axles with a capacity of 9 and 12 tons • Suspension: Parabolic dual-layer “Z” leaf springs and shock absorbers • Axle Lift System: Manual lift system on front and middle axles • Brake System: 71/320 brake system compliant with EC standards • Brake Chambers: 4 emergency brake chambers, 2 service brake chambers • Brake Adjusters: 6 automatic brake adjusters installed |
| Electrical System |
| • 2×7 or 15-pin, SAE standard complete lighting system • LED rear stop lights, 2 white LED front lights, 4 x 2 yellow LED side lights, 2 license plate lights |
| Tires and Rims |
| • (For 2 Axles) 4 x 385/65 R 22.5 or 8 x 12 R 22.5 • (For 3 Axles) 6 x 385/65 R 22.5 or 12 x 12 R 22.5 • (For 4 Axles) 8 x 385/65 R 22.5 or 16 x 12 R 22.5 |
| Paint |
| • After sandblasting, coated with 2+1 layers of epoxy primer and acrylic paint, cured in a special oven paint cabin |
| Standard Accessories |
| • 2’’ King Pin, compliant with R55 regulations • Liftable rear bumper, compliant with R58 regulations • Basket-type spare wheel carrier for one spare tire • 2 wheel chocks with holders • 2 ramp resting chocks • 4 anti-spray quarter mudguards, compliant with 109/2011 EEC regulations • Lockable sheet metal toolbox, 1 pc • Lighting-equipped, lockable food cabinet, 1 pc • Foldable side guards, compliant with R73 regulations • Retractable rear ladder for trailer access and 1 portable aluminum ladder • Fire extinguisher cabinet, 1 pc • 50-liter plastic water tank • 2 rear roller bump stops, side protection stops for forklift impacts (only for trailers with side covers) • 1 collapsible TIR plate compliant with R70 regulation, 2 reflectors, and reflective striping • 1 document case with technical documentation |
| King Pin |
| • 2″ or 3.5″ flanged, bolted, high-stress resistant, forged steel • Easily replaceable with screw connections • E-certified |
| Panels |
| • Panel height: Side and rear panels of the pilot trailer range from 500-800 mm (Standard: 720 mm) • Fixed front panel height: 1500 mm (Includes tarp support and climbing ladder) • Extendable pilot trailer model: Front panel height 1000 mm, removable with hinges • Flooring: Standard 30 mm resin-coated plywood (reinforced for forklifts) or diamond-pattern steel for alternative uses |
| Brakes |
| • 71/320 / EWG FF brake system in compliance with EC standards • Automatic brake slack adjusters, service brake compartments • EBS 2S/2M – 4S/2M – 4S/3M and RSS (Roll Stability Support) system |
| Optional Features |
| • 385/55 R 22.5 Tires • Additional row of aluminum profiles under the tarpaulin • 600 mm high, 10 side panels + side forklift impact protectors • Additional basket-type spare wheel carrier • Fixed bumper compliant with R58 regulation • 60-liter stainless steel water tank • Brake system features TIM/SmartBoard • Anti-vandal tarpaulin • 1 lug wrench and handle • 1 fire extinguisher (ADR compliant) • If ADR compliance is required, 1×15-pin socket electrical system • EN 12642 Code XL Load Safety Certification • Dual FH adjustable suspension system |
- Files not yet loaded
Gallery not yet loaded
Media not yet loaded
What are platform-type trailers? What are its features?
The platform trailer, which is actively used in the industrial field, is successfully designed by Vertisa according to the demands. Vertisa offers solutions to the platform trailer needs of many countries in European standards. Platform trailer general features;
- Platform trailer provides safe transportation of the load.
- It can maneuver solidly.
- The axles on the trailer can be steered by the user.
- It has a double-acting hydraulic suspension for driving safety.
- The platform trailer does not have a central spine. Thus, it can be easily moved in a narrow space.
- It has a carrying capacity of up to 100 tons.
Platform trailer types produced by Vertisa for transportation operations; flatbed semitrailers and curtain sider trailers.
Trailer production for every region of the world!
Contact Us for All Your Questions!
Flat Bed Semi-Trailer
A flatbed semi-trailer has a flat platform. They are vehicles used for the transportation of heavy and long loads. It is produced according to the legal road conditions of each country. Different types of flatbed trailer options have emerged in line with the needs of the transportation industry. Loading the load on the platform from the top and sides is very practical in all flatbed types.
Vertisa; carries out the production of lowboy, step deck, removable gooseneck trailer, and more on a project-based European quality standard.
Curtainsider Trailer
Curtainsider, which has a curtain that protects the load from external factors, is used in long-distance transportation. Vertisa designs and manufactures curtainsider trailer types such as Maxima plus, mega, and double-decker, for the transportation sector, according to the needs.
Platform Trailer Dimensions
Platform trailer dimensions can be designed and produced by Vertisa according to the needs. Platform trailer dimensions are produced in the required dimensions to meet traffic safety standards, without being bound by a certain standard. You can contact our technical teams immediately to get more detailed information about platform-type trailer dimensions for your projects.
Platform Trailer Manufacturers
Platform trailer manufacturers have to comply with the transportation and highway standards of the relevant country while offering solutions to their users in the transportation and logistics sector. Vertisa observes all European standards, especially Turkey, in all projects it provides to its users. It offers its users optimum products by considering the current conditions. It never compromises on quality standards in production. The production team, which constantly adapts itself to the latest technology, always aims to move the industry-standard forward with its innovative perspective on the industry.
Platform Trailer Types
Platform trailer types are known by many different names and types in the sector. These platform type trailer types and names are mainly; They are low platform trailer, car platform trailer, semi-trailer platform, and enclosed trailer models.
Low platform trailer
The low platform, specially designed and manufactured by Vertisa, is frequently preferred by logistics companies in long-distance heavy cargo transportation.
Car platform trailer
It is a platform trailer model used for car transport. Vertisa designs and manufactures the car platform according to the needs.
Semi-trailer platform
A semi-trailer platform is a platform trailer model used in dry cargo transportation between 20 and 80 tons. The semi-trailer designed and manufactured by Vertisa in special structures for each payload has high performance in all climatic and road conditions.
Enclosed trailer
The closed platform trailer is designed and produced by Vertisa Trailer according to the needs. Closed platform trailers, which can be produced in desired width and length, are used for loads that need to be transported indoors. In addition, some institutions or organizations use closed platforms as warehouses.
Platform Trailer Prices
The general characteristics of the platform trailer are transferred to the Vertisa technical teams by its users. Vertisa technical staff projects the expected product to give the best solution to customer needs. Vertisa optimizes platform trailer prices without compromising product quality in all projects it provides to its users. Platform trailer prices are generally determined according to the projects needed and offered to the users before the project.
